            多列四邊封包裝機







            多列四邊封包裝機特點及參數 EQUIPMENT FEATURE AND PARAMETER

            可實現定制化多種計量方式
            It can achieve various customized metering methods

            可滿足審計追蹤、電子簽名、數據統計等功能
            It can meet functions such as audit trails, electronic signatures, and data statistics

            配置18.5寸超大工控屏,全新人機交互界面
            Equipped with an 18.5-inch large industrial control screen and a newly designed human-machine interface

            采用全伺服控制系統,提升OEE設備綜合效率
            Uses a full servo control system to enhance OEE

            符合EHS管理要求
            Complies with EHS management reguirements

            穩定速度可達70-80切/分鐘
            Stable speed can reach 70-80 cuts per minute

            具備自動充氮功能,殘氧可控制在2%以內
            Equipped with an automatic nitrogen flling function,with residual oxygen controlled within 2%

            可實現后端定制化整線多種解決方案,助力企業無人化生產
            Can provide customized end-to-end solutions,supporting automation in production for businesses

            型  號

            Model

            MF-600

            MF-1000

              數

            Lane number

            4-8(Lane)

            6-10(Lane)

            計量方式

            Measuring Mothod

            陶瓷泵Ceramic pump長螺桿Long screw短螺桿Short screw量杯Volumetric Cup數粒機electronic granulation counter

            包裝速度

            Capacity

            50-100//分鐘50-100 bags/Lane/minute

            充填容量

            Filling capacity

            粉劑powder:0.5-50g   顆粒劑Granule:0.5~30g  液體liquid:5-50ml  丸劑、片劑Pillstablets:1-120pc

            制袋尺寸

            Sachet size

            2分割100-200 mm/3分割80-100mm/4分割55-100mm/6分割40-60mm2 divisions100-200mm /3 divisions80-100mm /4 divisions55-100mm/6 divisions40-60mm

            膜寬

            Film width



            最大膜寬Max.600mm



            最大膜寬Max.1000mm

            封口形式

            Sealing type

            四邊封 Four side sealing

            切口形式

            Cutting type



            平口切Straight cutting鋸齒切Zig zag cutting圓角切Round corner cutting異形切Die-cut

            氣壓功率

            Air&Power



            0.4-0.6Mpa/0.5m3/min; 8-14kw

            尺寸重量

            Dimension&weight



            2260*1650*3500mm/3300kg



            2460*1650*3500mm/3500kg

            多列包裝機包裝樣袋:
